Product Details
Place of Origin: China
Brand Name: CN Crusher
Certification: ISO9001
Model Number: PFL-1500 III
Payment & Shipping Terms
Minimum Order Quantity: 1 Set
Price: Negotiate
Packaging Details: Standard package or as request
Delivery Time: To be negotiated
Payment Terms: TT, L/C
Supply Ability: 60 Set/Sets per Month
Name: |
Compound Cone Crusher |
CAPACITY: |
50 - 70TPH |
INPUT SIZE: |
< 180mm |
APPLICATION: |
Minerals, Cement, Construction Sand, Stone Stock |
OUTPUT SIZE MM: |
< 3 , 70 - 90% |
ROTOR SPEED: |
430 - 640RPM |
Name: |
Compound Cone Crusher |
CAPACITY: |
50 - 70TPH |
INPUT SIZE: |
< 180mm |
APPLICATION: |
Minerals, Cement, Construction Sand, Stone Stock |
OUTPUT SIZE MM: |
< 3 , 70 - 90% |
ROTOR SPEED: |
430 - 640RPM |
Quick Details
Compound Cone Crusher is widely used in all kinds of minerals, cement, construction sand, stone stock, slag, etc. Sand Making Machine is more productive than other kinds of crushers.
Working Principle
PFL-Ⅲ (ⅢX) series is designed according to the principle of increasing the input energy of materials step by step and crushing them step by step. After the material falls into the crushing cavity, it is first thrown out at high speed by the throwing tray, and hits the impact plate to form primary crushing. Then it falls into the gap between the hammer head and the impact plate, and the gap gradually decreases from top to bottom. The material is subjected to crushing forces such as impact, extrusion, and grinding of the hammerhead, and gradually changes from large to small, and finally reaches the set particle size, and is discharged from the crusher.
| MODEL | INPUT SIZE MM | OUTPUT SIZE MM | ROTOR SPEED RPM | MOTOR KW | CAPACITY TPH |
| PFL-750 III | < 100 | < 3 , 70 - 90% | 800 - 1350 | 45 | 8 - 20 |
| PFL-1000 III | < 120 | < 3 , 70 - 90% | 650 - 980 | 55 | 15 - 30 |
| PFL-1250 III | < 150 | < 3 , 70 - 90% | 510 - 770 | 90 | 30 - 45 |
| PFL-1250 IIIX | < 150 | < 3 , 70 - 90% | 510 - 770 | 90 | 30 - 45 |
| PFL-1500 III | < 180 | < 3 , 70 - 90% | 430 - 640 | 132 | 50 - 70 |
| PFL-1500 IIIX | < 180 | < 3 , 70 - 90% | 430 - 640 | 132 | 50 - 70 |
| PFL -1750 III | < 200 | < 3 , 70 - 90% | 420 - 540 | 160 | 70 - 100 |
| PFL-1750 IIIX | < 200 | < 3 , 70 - 90% | 420 - 540 | 160 | 70 - 100 |
| PFL-2000 III | < 220 | < 3 , 70 - 90% | 360 - 500 | 200 | 90 - 120 |
| PFL-2300 IIIX | < 240 | < 3 , 70 - 90% | 330 - 450 | 250 | 120 - 160 |
| PFL-2500 III | < 220 | < 3 , 70 - 90% | 360 - 500 | 200 | 90 - 120 |
Large crushing ratio
The maximum feed particle size is 80~240mm, and the output particle size is ≤3mm, accounting for about 90%.
High Yield
The crushing process is straight-through crushing, and the output is high due to the large amount of material passing through and the fast passing speed. Relatively speaking, the energy consumption is less.
Energy efficient
This machine is used in conjunction with the mill, which can increase the output of the mill by about 40%, and reduce the power consumption of the system by about 30%.
Consumable parts wear less and have a long life
The wearing parts are made of high-hardness, high-toughness multi-element alloy wear-resistant material, with less wear and long life. The distance between the hammer head and the impact plate can be fine-tuned to ensure uniform particle size, the utilization rate of the hammer head is greatly improved, and the service life is increased by about 5 times.
Optimized rotor design
Through the optimized design of the rotor part, this machine forms a multi-stage continuous crushing cavity, which makes full use of energy and space, thereby improving the performance of the machine.
Barrel parts are of open design
It is convenient to replace the vulnerable parts such as the hammer head and the impact plate. Unique throwing tray structure
It is composed of throwing ribs and throwing lining boards, which are distributed in circles. After the throwing ribs are worn out, they can be used as throwing linings, which greatly improves the utilization rate of materials and reduces the cost of use.
Application cooling system and bearing temperature detection device
It can crush high-temperature materials below 150°C, and can detect the bearing temperature in real time.
Compound Cone Crusher is used in Limestone, Granite, Basalt, River Stones, Quartz, Copper Ore, Iron Ore, Marble, etc.
